Tyler Pipe Company 009054 is a 4" x 4" x 4" x 4" straight gray cast iron double combination wye and 1/8 bend with no-hub (NH) connections.
A double combination brings two long-turn branches into the main line from opposite sides, used for back-to-back fixture drains in one fitting.
Sizes are listed as 4" x 4" x 4" x 4"; confirm the run and branch sizes against your layout, and join each no-hub end with a no-hub coupling of the matching size.
Specifications
-
Brand: Tyler Pipe Company
-
Manufacturer Part #: 009054
-
Size: 4" x 4" x 4" x 4"
-
Connection: NH x NH x NH x NH
-
Material: Gray cast iron
-
Fitting Type: Double combination wye and 1/8 bend
-
Pattern: Straight
-
Category: No Hub Fittings
-
Shipping Weight: 17.7 lb
